Os2 Fiber Optic Cable
Yam khoom: OS2 Fiber Optic Cable
Qauv: 12 Strand OSP Sab Nraum Qhuav Loose Tube, Tsis yog Armored, Txhua Dielectric, OS2 9/125 Tib Hom Fiber Optic Cable
- Khoom Taw qhia
Qhov no OS2 Fiber Optic Cable yog tsim los ntawm ib tug mus rau rau sub-units, dej thaiv cov xov paj, dielectric zog khoom, ib tug aramid ripcord, thiab ib tug MDPE lub tsho sab nrauv. Txhua sub-unit muaj 12 xim iav fibers thiab dej swellable xov paj nrog ib lub tsho MDPE 3 hli inch. Tag nrho cov khoom siv ua tau raws li EU RoHS thiab REACH Cov Lus Qhia. Sub-units yuav ua tau xim-coded los yog sequentially numbered.
OS2 Fiber Optic Cable muaj nyob rau hauv 12 TIA tus qauv xim lossis xim tshwj xeeb. Tus qauv nto luam tawm qhia txog kev tsim kho, NEC kev ntsuas, thiab hom fiber ntau, thiab suav nrog cov cim kos duab. Kev cai luam ntawv kuj tuaj yeem haum.
Specification:
|
Specification thiab Tsim |
|||||
|
Fiber suav |
12-72 |
84-96 |
108-144 |
192-216 |
240-288 |
|
Cable Outer Diameter npe. Ntiv (mm) |
0.41(10.5) |
0.48(12.2) |
0.59(15.1) |
0.61(15.6) |
0.71(18.1) |
|
Cable Nyhav Nom. lb/kft (kg/km) |
50(75) |
70(105) |
107(160) |
107(160) |
145(215) |
|
Fiber Xim Xim |
Xiav, Txiv kab ntxwv, Ntsuab, Xim av, Slate, Dawb, Liab, Dub, Daj, Violet, Rose, Aqua |
||||
|
Max. Fiber rau Tube |
12 |
||||
|
Tus naj npawb ntawm Tube Txoj Haujlwm |
6 |
8 |
12 |
18 |
24 |
|
Tus naj npawb ntawm Active Tube |
1-6 |
7-8 |
9-12 |
16-18 |
20-24 |
|
Tube Xim Xim |
Xiav, Txiv kab ntxwv, Ntsuab, Xim av, Slate, Dawb, Liab, Dub, Daj, Violet, Rose, Aqua Blue *, Txiv kab ntxwv *, Ntsuab *, Xim av *, Slate *, Dawb *, Liab *, Dub **, Daj * , Violet * , Rose * , Aqua * |
||||
|
Cov khoom thaiv dej |
Dej Swellable xov paj thiab daim kab xev |
||||
|
Central Strength Member |
FRP (Fiber Reinforced Yas) |
||||
|
Jacket Khoom |
Dub xim polyethylene |
||||
*: Tube nrog dub taug qab
**: Tube nrog cov kab dawb
Nta rau OS2 Fiber Optic Cable:
• Txhua yam qhuav (Gel-dawb): Kev npaj yooj yim
• Xim-coded fibers: Ib qho yooj yim thiab ceev qhia
• Kev tsim lub raj xoob: kev ua haujlwm ruaj khov thiab kev sib raug zoo nrog txhua hom fiber ntau
• All-dielectric kev tsim kho
Daim ntawv thov:
• Local Area Network (LAN)
• Kev Pabcuam Network System
• Long Haul Communication System
• Aerial, Direct faus, Duct
